基本型号 Model |
工业化生产用组合型 Combination type for industrialized production |
|
技术指标 Specifications |
2×A50
|
2×A75
|
2×A100
|
2×A125
|
2×A150
|
2×A200
|
|
加热板名义面积 m2 |
100
|
150
|
200
|
250
|
300
|
400
|
|
Nominal area of heating plates (m2) |
|
设计最大捕水能力kg/h |
230
|
350
|
460
|
560
|
680
|
900
|
|
Max.design water trapping capability （kg/h) |
|
加热板温调节范围 |
30-120
|
30-120
|
30-120
|
30-120
|
30-120
|
30-120
|
|
Operating temperature of heating plates |
|
正常最低工作压力 Pa |
45
|
45
|
45
|
45
|
45
|
45
|
|
Normal min. Working pressure(Pa) |
|
空载抽空时间 min |
5
|
8
|
12
|
15
|
15
|
15
|
|
Evacuaired time with empty loading(min) |
|
配套冷量 kw |
158
|
240
|
320
|
360
|
480
|
650
|
|
Required cold capacity(kw) |
|
最大蒸汽耗量（0.7MPa)kg/h |
220
|
360
|
480
|
540
|
720
|
960
|
|
Max.vapor consumption (MPa)kg/h |
|
装机功率 kw |
89
|
90
|
115
|
115
|
1269
|
165
|
|
Installation power (kw) |
|
经济组合型式 |
(2*A/75/100/125/150/200) (4*A/75/100/125/150/200) |
|
Economic combination type |
(6*A/75/100/125/150/200) (8*A/75/100/125/150/200) |
|
注:不同的经济组合技术指标会有所不同,4×或6×或8×等越多组合能耗指标会越低。 |
|
